Context and Problem Statement​

In the openMCP platform, we need to determine how to organize resources in the Platform Cluster that belong to Managed Control Planes (MCPs). Each MCP represents a separate tenant or customer environment that needs to be isolated and managed independently. The key question is: Should every MCP on the Platform Cluster have its own Namespace to ensure proper isolation, resource management, and security boundaries?

Without proper namespace isolation, MCPs could interfere with each other, leading to security vulnerabilities, resource conflicts, and operational complexity.

Considered Options​

1. mcp-{hash-mcp-name-and-namespace} - Create namespaces using a hash of the MCP name and original namespace (hash < 63 chars)
2. mcp-{uid} - Create namespaces using the UID of the MCP resource

Decision Outcome​

Option 1: mcp-{hash-mcp-name-and-namespace, because it provides unique namespace isolation for each MCP while avoiding conflicts and maintaining deterministic naming that survives backup/restore operations. Option 2 would have been simpler but does not work well with backup/restore scenarios, as the UID changes after a restore operation, breaking the link between the MCP and its namespace.

The hash algorithm we will use with Option 1 is SHAKE128. It is an 128-bit algorithm that is FIPS compliant. The 128-bit output allows us to print the hash in the UUID v8 format. So the namespace could look something like mcp-3f4b2c1d-8e9a-7b6c-5d4e-3f2a1b0c9d8e.

Consequences​

• The old hash function K8sNameHash should not be used anymore.

Context and Problem Statement​

When creating services on a Kubernetes cluster, they shall be accessible from other clusters within an openMCP landscape. To achieve this a Gateway and HTTPRoute resource is created. The Gateway controller will assign a routable IP address to the Gateway resource. The HTTPRoute resource will then be used to route traffic to the service.

apiVersion: gateway.networking.k8s.io/v1beta1
kind: Gateway
metadata:
  name: example-gateway
  namespace: default
spec:
  gatewayClassName: openmcp
  listeners:
    - name: http
      protocol: HTTP
      port: 80
      allowedRoutes:
        namespaces:
          from: Same
status:
    addresses:
      - type: IPAddress
        value: "172.18.201.1"
---
apiVersion: gateway.networking.k8s.io/v1beta1
kind: HTTPRoute
metadata:
  name: example-route
  namespace: default
spec:
  parentRefs:
    - name: example-gateway
  hostnames:
    - svc-abc123.workload01.openmcp.cluster
  rules:
    - matches:
        - path:
            type: PathPrefix
            value: /
      backendRefs:
        - name: example-svc
          port: 80

The problem is that the service is only reachable via the IP address and not via the hostname. This is because the DNS server in the openMCP landscape does not know about the service and therefore cannot resolve the hostname to the IP address. The Kubernetes dns service only knows how to route to service within the same cluster. On an openMCP landscape however, services must be reachable from other clusters by stable host names.

Therefore there is a need for a openMCP DNS solution that makes these host names resolvable on all clusters that ar part of the openMCP landscape.

openMCP DNS System Service​

To solve the stated problem, a openMCP DNS System Service is needed. This system service will be responsible for the following tasks:

• Deploy a central openMCP DNS server in the openMCP landscape. This DNS server will be used to resolve all host names in the openMCP base domain openmcp.cluster.
• For each cluster in the openMCP landscape, the system service will configure the Kubernetes local DNS service to forward DNS queries for the openMCP base domain to the central openMCP DNS server. This will ensure that all clusters can resolve host names in the openMCP base domain.
• For each Gateway or Ingress resource, the system service will create a DNS entry in the central openMCP DNS server. The DNS entry will map the hostname to the IP address of the Gateway or Ingress resource.
• For each cluster in the openMCP landscape, the system service will annotate the Cluster resource with the openMCP base domain. This will help service providers to configure their services to use the openMCP base domain for their host names.

This shall be completely transparent to a service provider. The service provider only needs to create a Gateway or Ingress resource and the DNS entry will be created automatically.

Example Implementation​

For the example implementation, following components are used:

• External-DNS
• CoreDNS
• ETCD

The DNS Provider is running on the platform cluster. The DNS Provider is deploying an ETCD and the cental CoreDNS instance on the platform cluster. The ETCD instance is used to store the DNS entries. The CoreDNS is reading the DNS entries from the ETCD instance and is used to resolve the host names.

# CoreDNS configuration to read DNS entries from ETCD for the openMCP base domain `openmcp.cluster`
- name: etcd
    parameters: openmcp.cluster
    configBlock: |-
      stubzones
      path /skydns
      endpoint http://10.96.55.87:2379

The DNS Provier is reconciling Cluster resources. For each Cluster resource, the DNS Provider is deploying an External-DNS instance on the cluster. The External-DNS instance is used to detect the Gateway and Ingress resources and to automatically create the DNS entries in the ETCD instance running on the platform cluster.

# external-dns configuration to detect Gateway and Ingress resources and write DNS entries to ETCD
containers:
    - name: external-dns
    image: registry.k8s.io/external-dns/external-dns:v0.16.1
    args:
    - --source=ingress
    - --source=gateway-httproute
    - --provider=coredns
    - --domain-filter=platform.openmcp.cluster # only detect hostnames in the openMCP base domain belonging to the cluster
    env:
    - name: ETCD_URLS
        value: http://172.18.200.2:2379 # external routable IP of the ETCD instance running on the platform cluster

The DNS Provider is updating the CoreDNS configuration on the platform cluster and on all other clusters. The CoreDNS configuration is updated to forward DNS queries for the openMCP base domain to the central CoreDNS instance running on the platform cluster. This will ensure that all clusters can resolve host names in the openMCP base domain.

openmcp.cluster {
    forward . 172.18.200.3
    log
    errors
}

Then on any pod in any cluster of the openMCP landscape, the hostname can be resolved to the IP address of the Gateway or Ingress resource.

Context and Problem Statement​

(Describe the context and problem statement, e.g., in free form using two to three sentences or in the form of an illustrative story. You may want to articulate the problem in form of a question and add links to collaboration boards or issue management systems.)

Considered Options​

• (title of option 1)
• (title of option 2)
• (title of option 3)
• …

Decision Outcome​

Chosen option: "(title of option 1)", because (justification. e.g., only option, which meets k.o. criterion decision driver | which resolves force (force) | … | comes out best (see below)).

Consequences​

• Good, because (positive consequence, e.g., improvement of one or more desired qualities, …)
• Bad, because (negative consequence, e.g., compromising one or more desired qualities, …)
• …
